iOS

1. Installation

How to install Preventor iOS SDK

Requirements

The latest stable version of Xcode, since the SDK is written in Swift 5.7.1

Minimum target: iOS 13.0.

Install via CocoaPods

To always use the latest release, add the following to your Podfile:

pod 'PreventorSDK'

Alternatively, pin to a specific version (e.g. 0.2.2):

pod 'PreventorSDK', '2.1.0'

And then run:

pod install

Install via Swift Package Manager

import PackageDescription

let package = Package(
  name: "YourTestProject",
  platforms: [
       .iOS(.v13),
  ],
  dependencies: [
    .package(name: "PreventorSDK", url: "https://github.com/preventorid/button-ios-sdk.git", from: "2.1.0)
  ],
  targets: [
    .target(name: "YourTestProject", dependencies: ["PreventorSDK"])
  ]
)

Adding it to an existent iOS Project via Swift Package Manager

Using Xcode go to File > Swift Packages > Add Package Dependency
Paste the project URL: https://github.com/preventorid/button-ios-sdk.git
Click on next and select the project target
Don't forget to set DEAD_CODE_STRIPPING = NO in your Build Settings (https://bugs.swift.org/plugins/servlet/mobile#issue/SR-11564)

2. Initialize SDK

For integration, you need to configure the pre-padding shown below. You must first implement the PSDKConfig structure.

Credential prefill

self.config = PSDKConfig(flowID: "YOUR_FLOW_ID",
                         cifCode: "YOUR_CIFCODE",
                         apiKey: "YOUR_API_KEY",
                         tenant: "YOUR_TENANT",
                         env: "YOUR_ENV",
                         banknu: "YOUR_BANKNU",
                         secret: "YOUR_CLIENT_SECRET",
                         invitation: "YOUR_INVITATION_ID",
                         broker: "YOUR_BROKER")

If the cifCode is empty or nil, a unique code is assigned.

Value

Description

YOUR_FLOW_ID

Defines the biometric process

UNIQUE_CUSTOMER_CODE

Is the unique customer profile code.

YOUR_API_KEY

Your provided apikey.

YOUR_CLIENT_SECRET

Your provided clientsecret.

YOUR_TENANT

Your provided tenant.

YOUR_BANKNU

Your provided banknu.

YOUR_ENV

Your provided env.

YOUR_INVITATION_ID

Your invitation ID

YOUR_BROKER

Your broker

To initialize the SDK, you need to call the initialize(config: PSDKConfig) method:

self.config = PSDKConfig(flowID: "YOUR_FLOW_ID",
                         cifCode: "YOUR_CIFCODE",
                         apiKey: "YOUR_API_KEY",
                         tenant: "YOUR_TENANT",
                         env: "YOUR_ENV",
                         banknu: "YOUR_BANKNU",
                         secret: "YOUR_CLIENT_SECRET",
                         invitation: "YOUR_INVITATION_ID",
                         broker: "YOUR_BROKER")
PSDK.shared.initialize(config: config)

3. Start the Verification

To start a new verification, you first need to create the PreventorButton

Add Button via Storyboard

Two simple steps to get the button running:

Drag a new button on your storyboard and give it your desired constraints.
Subclass the button as PreventorButton. Ensure that the module also says PreventorSDK below the class.

Add PreventorButton in your project programmatically

import SwiftUI
import PreventorSDK

struct ContentView: View {

    @ObservedObject var store: ContentViewModel
    let config: PSDKConfig

    var body: some View {
        PreventorButton()
    }

    init() {
        self.config = PSDKConfig(flowID: "YOUR_FLOW_ID",
                                 cifCode: "YOUR_CIFCODE",
                                 apiKey: "YOUR_API_KEY",
                                 tenant: "YOUR_TENANT",
                                 env: "YOUR_ENV",
                                 banknu: "YOUR_BANKNU",
                                 secret: "YOUR_CLIENT_SECRET",
                                 invitation: "YOUR_INVITATION_ID",
                                 broker: "YOUR_BROKER")
        PSDK.shared.initialize(config: config) { isSuccessful in
             //your code
        }
    }
}

class ContentViewModel: ObservableObject, PSDKDelegate {
    //YOUR IMPLEMENTATION
    func updatePreventorSDKDelegate() {
        PSDK.shared.delegate = self
    }

    func onStart() {
        print("onStart")
    }

    func onFinish(result: PSDKResult) {
        print("onFinish")
    }

    func onError(error: PSDKErrorCode) {
        print("error:", error.rawValue)
    }

    func onSubmitted(result: PSDKResult) {
        print("onSubmitted")
    }

}

import UIKit
import PreventorSDK

class ViewController: UIViewController {

    override func viewDidLoad() {
        super.viewDidLoad()
        // Add the button with dimensions
        let button = UIPreventorButton(frame: CGRect(x: 40, y: 90, width: 300, height: 60))
        self.view.addSubview(button)

        // Or Add button with autolayout support
        let button = UIPreventorButton(frame: .zero)
        button.translatesAutoresizingMaskIntoConstraints = false
        self.view.addSubview(button)
        let buttonConstraints = [
                button.leadingAnchor.constraint(equalTo: view.leadingAnchor, constant: 50.0),
                button.trailingAnchor.constraint(equalTo: view.trailingAnchor, constant: -50.0),
                button.topAnchor.constraint(lessThanOrEqualTo: self.view.topAnchor, constant: 60.0),
                button.heightAnchor.constraint(equalToConstant: 40),
        ]
        NSLayoutConstraint.activate(buttonConstraints)
        updatePreventorSDKDelegate()
    }

}

extension ViewController: PSDKDelegate {
    //YOUR IMPLEMENTATION
    func updatePreventorSDKDelegate() {
        PSDK.shared.delegate = self
    }

    func onStart() {
        print("onStart")
    }

    func onFinish(result: PSDKResult) {
        print("onFinish")
    }

    func onError(error: PSDKErrorCode) {
        print("error:", error.rawValue)
    }

    func onSubmitted(result: PSDKResult) {
        print("onSubmitted")
    }

}

Start Verification

To start a check, just click the PreventorButton

Adjust Your App's Permissions

If you made it until here, you've successfully installed the Preventor SDK for iOS. Now let's adjust your last settings and start your first verification.

Please add the following permissions to your app's Info.plist, so that the Preventor iOS SDK can access a user's camera to run a verification. You can do this in the property list view or by code.

Right-click somewhere outside the table and select Add Row. Now add the entries like below.

Or if you prefer to do this step with code, right-click on Info.plist and select Open As -> Source Code. Add the lines below somewhere inside the <dict> </dict>

<!-- permission strings to be include in info.plist -->
<key>NSCameraUsageDescription</key>
<string>Please give us access to your camera, to complete the verification.</string>
<key>NSLocationWhenInUseUsageDescription</key>
<string>Please give us access to your location to complete the verification.</string>
<key>NSLocationWhenInUseUsageDescription</key>
<string>Please give us access to your location to complete the verification.</string>
<key>NSPhotoLibraryUsageDescription</key>
<string>Please give us access to your photo library to verify you.</string>
<key>NFCReaderUsageDescription</key>
<string>Give us NFC access to complete verification.</string>
<key>com.apple.developer.nfc.readersession.formats</key>
<array>
	<string>TAG</string>
</array>
<key>com.apple.developer.nfc.readersession.iso7816.select-identifiers</key>
<array>
	<string>A0000002471001</string>
	<string>E80704007F00070302</string>
	<string>A000000167455349474E</string>
	<string>A0000002480100</string>
	<string>A0000002480200</string>
	<string>A0000002480300</string>
	<string>A00000045645444C2D3031</string>
</array>

You have successfully finished setting up the Preventor iOS SDK! 🎉

Customization

If you want to add your own customization you can use the following methods

Method

Description

setNavigationTitle

Use this method to change the navigation title of the SDK.

4. Handling Verifications

To find out if a user started, completed, canceled or failed the verification process, you can implement the following delegate methods:

Method

Description

onStart

This callback method is triggered once a user starts the verification flow.

onSubmitted

Method that is being called once verification data is submitted to Preventor.

onFinish

Method that is being called once a user clicks the "Finish" button.

onError

This callback method fires when a user canceled the verification flow, the verification ended with an error, or the user performed an incorrect process. You can use this to find out the reason for the error.

Error codes:

CANCELLED_BY_USER

BIOMETRIC_AUTHENTICATION_FAILED

BAD_STEP_BY_USER MISSING_PARAMETERS

onNextStep

This callback method is called when the SDK is ready to move on to the next check.

import SwiftUI
import PreventorSDK


struct ContentView: View {

    @ObservedObject var store: ContentViewModel
    let config: PSDKConfig

    var body: some View {
        PreventorButton()
    }

    init() {
        self.config = PSDKConfig(flowID: "YOUR_FLOW_ID",
                                 cifCode: "YOUR_CIFCODE",
                                 apiKey: "YOUR_API_KEY",
                                 tenant: "YOUR_TENANT",
                                 env: "YOUR_ENV",
                                 banknu: "YOUR_BANKNU",
                                 secret: "YOUR_CLIENT_SECRET",
                                 invitation: "YOUR_INVITATION_ID",
                                 broker: "YOUR_BROKER")
        PSDK.shared.initialize(config: config) { isSuccessful in
             //your code
        }
    }
}

class ContentViewModel: ObservableObject, PSDKDelegate {
    //YOUR IMPLEMENTATION
    func updatePreventorSDKDelegate() {
        PSDK.shared.delegate = self
    }

    func onStart() {
        print("onStart")
    }

    func onFinish(result: PSDKResult) {
        print("onFinish")
    }

    func onError(error: PSDKErrorCode) {
        print("error:", error.rawValue)
    }

    func onSubmitted(result: PSDKResult) {
        print("onSubmitted")
    }

}

import UIKit
import PreventorSDK

class ViewController: UIViewController{

    @IBOutlet weak var PreventorButton: UIPreventorButton!

    override func viewDidLoad() {
        super.viewDidLoad()
        // Add the button with dimensions
        let button = UIPreventorButton(frame: CGRect(x: 40, y: 90, width: 300, height: 60))
        self.view.addSubview(button)

        // Or Add button with autolayout support
        let button = UIPreventorButton(frame: .zero)
        button.translatesAutoresizingMaskIntoConstraints = false
        self.view.addSubview(button)
        let buttonConstraints = [
                button.leadingAnchor.constraint(equalTo: view.leadingAnchor, constant: 50.0),
                button.trailingAnchor.constraint(equalTo: view.trailingAnchor, constant: -50.0),
                button.topAnchor.constraint(lessThanOrEqualTo: self.view.topAnchor, constant: 60.0),
                button.heightAnchor.constraint(equalToConstant: 40),
        ]
        NSLayoutConstraint.activate(buttonConstraints)

        let config = PSDKConfig(flowID: "YOUR_FLOW_TYPE",
                                 cifCode: "YOUR_CIFCODE",
                                 apiKey: "YOUR_API_KEY",
                                 tenant: "YOUR_TENANT",
                                 env: "YOUR_ENV",
                                 banknu: "YOUR_BANKNU",
                                 secret: "YOUR_CLIENT_SECRET")
        updatePreventorSDKDelegate()
        PSDK.shared.initialize(config: config)
    }

}

extension ViewController: PSDKDelegate {
    //YOUR IMPLEMENTATION
    func updatePreventorSDKDelegate() {
        PSDK.shared.delegate = self
    }

    func onStart() {
        print("onStart")
    }

    func onFinish(result: PSDKResult) {
        print("onFinish")
    }

    func onError(error: PSDKErrorCode) {
        print("error:", error.rawValue)
    }

    func onSubmitted(result: PSDKResult) {
        print("onSubmitted")
    }

}

PreviousVue.js NextAndroid

Last updated 3 years ago
